Unverferth 1317 / NOT AVAILABLE

Extreme Unloading

• Dyna-Torque auger on models 1317 and 1117 combines a 22" diameter auger in the sump feeeding into a 20" diameter auger for unloading speeds up to 620 bushels per minute
  • By increasing the unloading rate out of the sump, unloading efficiency is improved compared to a conventional, full-length 22" diameter auger
• Model 1017 featuers a 20" diameter auger for unloading speeds up to 500 bushels per minute
• Auger intake (sump) is recessed below the floor line of the tank for complete clean out and faster unloading

  • Wheel operated clean out door for easy clean out and convenient pit dumping

Unloading Control

• Hydraulically controlled 4-Way directional downspout provides 4 feet of left/right and 2 feet of in/out control for easily topping off trucks
• Dual auger mounted unloading lights with hinge-mounted switch for accurate connection and easier night time unloading

Smooth Operation

• Patented auger features a U-Joint with flex-drive coupler for unmatched durability and angles the auger outward for extreme upward, outward and forward reach

• Patented cushioned upper auger connection for a smooth and stress-free auger engagement

• Upper and lower auger flighting is synchronized for greater capacity, dependability and smooth operation

• Computer-balancing virtually eliminates any vibration for smooth operation and longer life

• Exclusive, full-length Extended-Wear flighting is 7/16" thick for longer life

• Heavy-duty gearbox is static-rated at 330 h.p. and dynamic-rated at 153 h.p. for long-term, trouble-free use

  • Features an extra large 1 3/4" full-length output shaft and 5-pin drive hub connection to the auger for handling the toughest unloading scenarios, even wet corn

Tank Features

• Capacities of 1325, 1125 and 1025 bushels to fit your operation's needs
• Interior slopes are graphite coated for faster, cleaner unloading
• Flashing L.E.D. amber and red taillights, side marker lights, reflective markings and S.M.V. emblem for safer transport
• Front viewing ladder and front and rear laminated, shatterproof windows for easily viewing contents
• Hydraulically controlled flow control door with highly visible position indicator and externally mounted cylinder for easy maintenance

Construction

• Tubular steel mainframe with a truss design and 12-guage steel shell provides added strength for carrying the heaviest loads through the field
• Durable primer coating with your choice of tractor red or green oven-baked top coat of high-grade enamel for a smooth, automotive-like finish
  • Exposed seams are silicone sealed for corrosion resistance

Weatherguard Tarp

• Weather-Guard rollover tarp with heavy-duty 18-oz. canvas to protect load contents is standard on the model 1317 and 1117 and optional on the model 1017

Durability

• Model 1317 features 12-bolt hubs and models 1117 and 1017 feature 10-bolt hubs
  • All hubs are specifically designed with extra-reinforced gussets for greater lateral strength
• Spindles are are constructed of high-tensile alloy steel for 30% greater strength then larger mild steel

High-Flotation Singles

• Available on models 1317, 1117 and 1017 with many tire size options depending on model
• Tractor lug design on models 1317 and 1117 and tractor lug or diamond tread design on model 1017

Walking Tandem Duals

• Available on 1317 and 1117 and can be adjusted for 30" or 36" row spacings
• Innovative design allows the cart to trail easily through the field and features independent operation from front to rear, allowing the cart to "walk" over obstacles.
• The entire wheel assembly swings out for easier tire/wheel maintenance

Equalizer™ Track Systems

• Exclusive 42" wide track belt provides the widest footprint in the industry!
• Patented design features 8° of side-to-side camber and 20° of front-to-back pivot with independent movement of each track which provides uniform ground contact on uneven terrain for optimum flotation
• Available on model 1317:
  • 42" wide rubber track with 105" of ground contact length provides the largest footprint in the industry, over 60 square feet!
  • Four cast pivoting midrollers are on the same plane as the main idler wheels for optimum flotation
• Available on model 1117:
  • 42" wide rubber track with 87" of ground contact length provides a footprint of over 50 square feet
  • Two cast pivoting midrollers are on the same plane as the main idler wheels for optimum flotation
• Shallow belt tread design for greater flotation and traction and 40" main idler wheels with 10-bolt hubs for added durability
• All hubs are greaseable and feature triple-lip seals with a steel guard for optimum lubrication
• Hydraulic belt tensioning adjustment for easier track alignment, optimum ground contact and even weight distribution
• Standard auto-greaser system for automatic application at more frequent intervals for consistent lubrication

Traditional Track

• 36" wide rubber track with 105" of ground contact length is available on model 1317 with four cast pivoting midrollers that are on the same plane as the main idler wheels for optimum flotation
• 36" wide rubber track with 90" of ground contact length is available on models 1117 and 1017 with two cast pivoting midrollers that are on the same plane as the main idler wheels for optimum flotation
• 40" main idler wheels with 10-bolt hubs for added durability
• All hubs are greaseable and feature triple-lip seals with a steel guard for optimum lubrication
• Hydraulic belt tensioning adjustment for easier track alignment, optimum ground contact and even weight distribution
